| INCH | SIZE | INSET | RIM TYPE | HOLE | P.C.D. | BORE | 参考重量 |
|---|---|---|---|---|---|---|---|
| (mm) | |||||||
| 15 (P.C.D.100 -4H SIZE) |
7 1/2J | 25 | S(46mm) | 4 | 100 | φ65 | 5.0kg |
| 8J | 0 | M(56mm) | 4 | 100 | φ65 | 5.1kg | |
| 25 | S(46mm) | ||||||
| 15 (P.C.D.114.3 -4H SIZE) |
7 1/2J | 6 | M(56mm) | 4 | 114.3 | φ73.1 | 5.0kg |
| 8J | 0 | M(56mm) | 4 | 114.3 | φ73.1 | 5.1kg | |
| 9J | -15 | L(82mm) | 4 | 114.3 | φ73.1 | 5.4kg |
| INCH | SIZE | INSET | RIM TYPE | HOLE | P.C.D. | BORE | 参考重量 |
|---|---|---|---|---|---|---|---|
| (mm) | |||||||
| 17 (P.C.D.100 -4H SIZE) |
7 1/2J | 30 | S(45mm) | 4 | 100 | φ65 | 7.2kg |
| 8 1/2J | 30 | S(45mm) | 4 | 100 | φ65 | 7.7kg | |
| 17 (P.C.D.114.3 -4/5H SIZE) |
9J | -10 | L(80mm) | 5 | 114.3 | φ73.1 | 7.9kg |
| 20 | M(55mm) | 5 | |||||
| 9 1/2J | -15 | L(80mm) | 5 | 114.3 | φ73.1 | 8.1kg | |
| 10J | -20 | LL(90mm) | 5 | 114.3 | φ73.1 | 8.3kg |
